ibaPDA-Interface-SINUMERIK-Xplorer

ibaPDA Interface: SINUMERIK-Xplorer (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)
Manufacturer: iba-ag
SKU: 31.000033
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Communication interface - Data acquiring and recording with free signal selection from SINUMERIK CNC control Systems via standard communication interfaces without additional communication hardware (via TCP/IP)

Technical Data:

  • Extension license for an ibaPDA system adding the data interface SINUMERIK-Xplorer (interface to for up to 16 SINUMERIK NCUs)
  • Measured value acquisition directly from the NCK and Integrated Sinamics component of SINUMERIK CNC control systems
  • Connection via standard interfaces TCP/IP without additional hardware
  • No intervention in the control System necessary
  • Convenient selection of the signals with the symbol browser
  • Change or expansion of the signals to be measured without programming and without stopping the machine
  • Evaluation with ibaAnalyzer included
  • number of connections/modules: up to 16
  • Remark:
  • Requires an ibaPDA-V7 or an ibaPDA-V7-PLC- Xplorer license
  • Please provide with your order the dongle number of your existing ibaPDA system. The dongle number is required to generate a license upgrade for your system.
  • If there are more than 16 connections / modules required, the interface can be extended with additional 16 connections / modules with the license "one-step-up-Interface-SINUMERIK-Xplorer" This license extension can be used 15 times per interface and allows in total 256 connections / modules per interface.
  • Status:available
