ibaPDA-PLC-Xplorer

PLC-Xplorer: Data Acquisition for 64 signals with Xplorer-interfaces
Manufacturer: iba-ag
SKU: 30.681502

PLC access via system services, 64 signals - Features:

  • acquiring up to 64 signals via Xplorer interfaces
  • Data acquisition system with on-demand access to Operands/Symbols
  • Standard Data Access: via TCP/IP
  • without additional communication hardware
  • max. number of connections / modules per interface: 16

Allows access to:

  • SIMATIC systems (S7-Xplorer)
    - another data access via MPI/Profibus(for e.g. with CP5512,CP5612)
  • Codesys based systems (Codesys-Xplorer)
  • Allen Bradley systems PLC5 / SLC-5 /MicroLogix (AB-Xplorer)
  • Sigmatek systems (Sigmatek-Xplorer)
  • Beckhoff systems (TwinCat-Xplorer)
    - Supports TwinCAT-Version 2 and 3
  • B&R systems (B&R-Xplorer)
    - In addition a B&R PVI-Manager license is required for the data acquisition. This license must be ordered from B&R directly on extra costs!
  • Allen Bradley systems Control-/Compact-Logix (Logix-Xplorer)
  • Mitsubishi controllers MELSEC-Xplorer)
  • Bachmann Systems (Bachmann-Xplorer)
  • ABB AC800 PLCs (ABB-Xplorer)

Remarks:

  • License with a fixed price
  • No hardware interfaces (FOB / COM cards)
  • To add the latest Xplorer interfaces is possible by ordering "Upgrade-ibaPDA-PLC-Xplorer-Interfaces"
  • Xplorer interfaces for drive controller or Sinumerik machines can be licensed seperately
  • If additional ibaPDA functionality is required (e.g. signal extension, QPanel, data stores, other interfaces, etc.) this license must be upgraded first with "Upgrade-PLC-Xplorer to PDA-V7-64". After an upgrade all ibaPDA extension features can be ordered.
  • In conjunction with ibaCapture access to video cameras is supported
  • Protected by dongle
  • Supported operating systems: Windows 8.1 (x86/x64), Windows 10 (x86/x64), Windows 11 (x64), Windows Server 2012 (x64), Windows Server 2012 R2 (x64), Windows Server 2016 (x64), Windows Server 2019 (x64), Windows Server 2022 (x64)
  • With V7.2.3 or newer .NET Framework 4.8 is required
  • Contains software maintenance and support after the purchase for 2 years. Afterwards a software maintenance and support contract is required.



(HarmonizedCode:85234910,&nbspECCN:N, LKZ:DE, AG:N)
