ibaPADU-8AI-U

Process coupling: Analog and digital inputs (HarmonizedCode:84733080, ECCN:N, LKZ:DE, AG:N)
Tillverkare: iba-ag
Artikelnr: 10.100000

8A+8D inputs,+/-10V .. +/- 60V,16Bit ADCs, 1kHz - Parallel Analog Digital Unit 8 analog and 8 digital channels

  • This single device replaces all previous versions of voltage input devices. The desired voltage level is selected with a rotary switch. Please refer to the data sheet for more details.

Technical Specifications:

  • Manufacturer: iba AG
  • Input module with 8 digital and 8 analog voltage inputs
  • Rugged metal case (DIN rail construction)
  • Dimension (WxHxD): 2.1 in x 7.9 in x 5.6 in (53 mm x 200 mm x 141 mm)
  • Fiber optic connectors with ibaNet protocol 3MBit
  • Daisy chain of up to eight PADU devices with ibaNet protocol 3MBit via fiber optic cable
  • Power supply: 24V DC
  • Power consumption: typ. 4W, (max. 8W)
    ------
    Analog inputs:
  • Number: 8
  • Design: Galvanically isolated, single ended, separate ADC per channel
  • Resolution: 16 Bit
  • Filters:
    - R/C low-pass 4 kHz (permanent)
    - Digital Antialiasing Tschebyscheff 8th order 330 Hz (selectable with rotary switch)
    - Digital low-pass Butterworth 2nd 250 Hz (selectable with rotary switch)
  • Input level:
    ±10 V, ±24 V, ±60 V,(max. for all ranges: ±60 V)
  • Input impedance:
    - 100kOhm
    - 1 MOhm (high impedance; selectable with rotary switch)
  • Sample rate: 1ms /Sample
  • Accuracy: < 0.1 % of total measuring range
  • Electrical isolation AC 1.5kV
  • 16-pin clamp-type terminal included in delivery
    ------
    Digital inputs:
  • Numbers: 8
  • Design: Galvanically isolated, protected against reverse polarity, single ended
  • Input level:
    - ±24 V, max. ±60 V
  • Signal level:
    - Signal level log. 0 : > -6 V; < +6 V
    - Signal level log. 1 : < -10 V; > +10 V
  • Input current: 1mA, constant
  • 16-pin clamp-type terminal included in delivery

Special Remark:

  • Fiber optical links to any iba component with a 3MBit technology is possible
  • Connection to a PCMCIA-F card via RJ11 jack is possible

Status:available
