INSYS icom
.
INSYS icom is the perfect partner when it comes to remote access to machinery, plant and other equipment and transmission of their operating data. We work with commitment every day to advance digitalisation and the implementation of the IIoT
Router and gateways
With routers from INSYS icom you can network your systems quickly, reliably and securely! They have been developed for the most demanding requirements and flexible use.
Managed Services
In interaction with our routers, the user-friendly remote access solutions from INSYS icom enable you to concentrate on your core business. They create a secure VPN connection, ensure maximum availability and simplify router management.
Edge Computing
In addition, on our routers you can implement applications simply, securely and reliably. You can process machine data, connect SCADA and multi-clouds or monitor threshold values.
Sort by
SCR-L300 1.1
10020729
Industrial cellular router with NAT, VPN, firewall, 2 Ethernet Ports, 1 RS232, 2 digital inputs, 2 digital outputs;
5 separate IP networks, user roles, variable configuration profiles, icom SmartBox
4G/LTE: Pentaband Cat. 1, 2G/GSM: Dualband, GPRS/EDGE Class 12
5 separate IP networks, user roles, variable configuration profiles, icom SmartBox
4G/LTE: Pentaband Cat. 1, 2G/GSM: Dualband, GPRS/EDGE Class 12
Allround Antenna 5G/4G/3G/2G SMA
10022961
Compact premium antenna for screw or wall mounting, indoor or outdoor usage,
Height 8,2 cm, diameter 4,8 cm, 5 m cable, SMA (m), protection class IP66,
included sealing pad for screw mounting and steel angle for wall mounting
Frequency ranges: 617 - 960 MHz / 1710 - 6000 MHz (including 5G bands FR1 and US bands)
Height 8,2 cm, diameter 4,8 cm, 5 m cable, SMA (m), protection class IP66,
included sealing pad for screw mounting and steel angle for wall mounting
Frequency ranges: 617 - 960 MHz / 1710 - 6000 MHz (including 5G bands FR1 and US bands)
Antenna with hinge Wi-Fi 2.4 GHz rev. SMA
10000661
WLAN 2,4 GHz, max. gain 3 dBi, length: 140 mm, connector rev. SMA (m)
Begner M2M SIM (1 Year) License
10022053SIM
includes 1 annual license (cannot cancel within contract period)
Begner VPN Service (1 Year) License
10022053BS
includes 1 annual license (cannot cancel within contract period)
Magnetic Antenna 4G/3G/2G SMA
10019504
Height 72 mm, 3 m cable, SMA (m), protection class IP65
Frequency ranges: 698 - 960 MHz / 1710 - 2170 MHz / 2500 - 2700 MHz (including US bands)
Frequency ranges: 698 - 960 MHz / 1710 - 2170 MHz / 2500 - 2700 MHz (including US bands)
Magnetic Antenna MIMO 5G/4G/3G/2G SMA
10022963
Premium MIMO antenna with magnetic mounting, dual antenna for devices with 2 LTE antenna connectors,
Height 61 mm, width 150 mm, 2x 5 m cable, SMA (m), protection class IP65,
Frequency ranges: 698 - 960 MHz / 1710 - 3800 MHz (including major 5G bands FR1 and US bands)
Height 61 mm, width 150 mm, 2x 5 m cable, SMA (m), protection class IP65,
Frequency ranges: 698 - 960 MHz / 1710 - 3800 MHz (including major 5G bands FR1 and US bands)
Magnetic Antenna Wi-Fi 2.4 GHz rev. SMA
10019797
WLAN 2,4 GHz, max. gain 1.6 dBi, Height 7,2 cm, 1,5 m cable, connector rev. SMA (m), protection class IP67
Magnetic/screw/adhesive Antenna 4G/3G/2G SMA
10017462
Height 38 mm, 5m cable, SMA (m);
Frequency ranges: 824 - 960 MHz / 1710 - 2170 MHz
Frequency ranges: 824 - 960 MHz / 1710 - 2170 MHz
Outdoor Panel Antenna MIMO 5G/4G/3G/2G SMA
10022962
Premium MIMO antenna for wall, pole or desk mounting, dual antenna for devices with 2 LTE antenna connectors,
Height 155 mm, width 155 mm, 3 variable mounting brackets, 2x 5 m cable, SMA (m),
protection class IP65,
Frequency ranges: 698 - 960 MHz / 1710 - 3800 MHz (including major 5G bands FR1 and US bands)
Height 155 mm, width 155 mm, 3 variable mounting brackets, 2x 5 m cable, SMA (m),
protection class IP65,
Frequency ranges: 698 - 960 MHz / 1710 - 3800 MHz (including major 5G bands FR1 and US bands)
Outdoor Wall Antenna 4G/3G/2G SMA
10020596
Height 22 cm; with steel angle for wall mounting (total height 32.5 cm), 5 m cable, SMA (m), protection class IP65,
Frequency ranges: 699 - 960 MHz / 1710 - 2690 MHz (including US bands)
Frequency ranges: 699 - 960 MHz / 1710 - 2690 MHz (including US bands)
Outdoor Wall Antenna Wi-Fi rev. SMA
10022599
WLAN 2,4 GHz, height 27 cm, 2.5 m cable, connector rev. SMA (m), protection class IP54, with angle for wall mounting
Power supply 24V 15W
10022848
Power supply AC/DC, DIN-Rail mounting, class II double insulation
Output voltage 24 V DC, Output Power: 15 W, AC Input Voltage: 85 – 264 VAC,
DC Input Voltage: 120 – 370 VDC
Protections against short circuit / overload / over voltage
Size (W x H x D): 17.5 x 90 x 54.5 mm
Output voltage 24 V DC, Output Power: 15 W, AC Input Voltage: 85 – 264 VAC,
DC Input Voltage: 120 – 370 VDC
Protections against short circuit / overload / over voltage
Size (W x H x D): 17.5 x 90 x 54.5 mm
Roof Mount Antenna 4G/3G/2G SMA
10022309
Height 15,7 mm, length/width 80 x 76 mm, screw mounting, 3 m cable, SMA (m), protection class IP67
Frequency ranges: 698 - 960 MHz / 1710 - 2170 MHz / 2500 - 2700 MHz (including US bands)
Frequency ranges: 698 - 960 MHz / 1710 - 2170 MHz / 2500 - 2700 MHz (including US bands)
Wall power supply 24V 25W international
10022849
Power supply AC/DC with mains plug, suitable for desktop use, international
including exchangeable plug types for Europe, Great Britain, Australia, USA
Output voltage 24 V DC, Output Power: 25 W, AC Input Voltage: 90 – 264 VAC
Protections against short circuit / overload / over voltage
Cable ends with wire end ferrules for use with push-in terminals
Size (W x H x D): 33 x 72 x 57 mm
Size (W x H x D): 17.5 x 90 x 54.5 mm
including exchangeable plug types for Europe, Great Britain, Australia, USA
Output voltage 24 V DC, Output Power: 25 W, AC Input Voltage: 90 – 264 VAC
Protections against short circuit / overload / over voltage
Cable ends with wire end ferrules for use with push-in terminals
Size (W x H x D): 33 x 72 x 57 mm
Size (W x H x D): 17.5 x 90 x 54.5 mm
