ibaBM-PN

Bus Monitor Profinet 2 Devices -

• 2 independend internal PN-Devices for to connect 1 or 2 PROFINET drops
• Aquiring and recording max. 1440 Bytes/PN-Device
• Sniffing functionality without repercussions in the PROFINET network with by data gathering
• Supports RT- (Real Time) and IRT-communication (Isochronous Real Time)
• Supports MRP (Media Redundancy Protocol)

Technical data:

• Manufacturer: iba AG
• Power supply: DC 24 V ±10%, not stabilized,
  2-pin connector with spring terminal, included
• Power consumption: Max. 9,6 W
  -----
  PROFINET-Interfaces:
• Numbers: 3 (2 x PROFINET Devices for max. 2 PROFINET drops, 1 x passive Sniffer)
• PROFINET Devices: 2 x 2-Port-Switches (2x RJ45-jacks, 10/100 Mbit/s)
• TAP interface (passive Sniffer): 2-Port-TAP, 2x RJ45-jacks, 10/100 Mbit/s
• Functions:
  2x PROFINET Device, shared device (max. 4 Controller),RT, IRT (>= 250µs), MRP Client
  -----
  ibaNet-Interface:
• Number: 1 (e.g. for connection with ibaPDA)
• ibaNet-Protocol: 32Mbit Flex
  Allows to us in parallel up to 15 devices in a ring topology, usable for data, setup and service information (e.g. updates)
• Data transmission rate: 32 Mbit/s
• Connection type: 2 ST connectors for fiber optic cable (62,5/125 µm) on RX and TX, max. 2000 m cable length without repeater
  -----
  Environmental conditions:
• Cooling: Passive
• Operating temperature: 0 °C to 50 °C
• Storage and transportation temperature: -25 °C to 70 °C
• Humity class acc. to DIN 40040: F
• Protection class: IP20
• Monting: DIN rail clamp, vertical
• Certification:
  EMV: IEC 61326-1 ; FCC part 15 class A
• Dimension (Width x Hight x Depth): 41 mm x 188 mm x 141 mm (incl. clamp for Din-rail mounting)

Special remarks:

• Profinet connection: via drop cable (RJ45 jack)
• For the connection with an ibaPDA-System a bidirectional fiber optic link with a FO-I/O-card, type FOB D, is required.

Status:on request
