ibaQDR

Length-based Quality Data in any resolution

Continuous processing lines need length-based quality data for product qualification. The quality data recording system ibaQDR acquires data time-based at different measuring locations and assigns the measurement values precisely to the length position of the product.






  • Recording system for quality data, based on ibaPDA architecture
  • Technological process des­cription of strip processing lines
  • Length normalization to the final product (exit coil) and synchronization of all measured data
  • Consideration of strip elongation in the process and all cuts
  • Standard length resolution: 1 m (fully adjustable incl. unit)
  • Scalable number of measuring locations and signals
  • Integration of ibaCapture data
  • Additional time-based recording as an option
  • Data storage in iba *.dat format related to the exit coil and additional to the entry coil

Sortera på
Visa per sida

ibaQDR-256-6

35.702560
Quality Data Recording with 256 signals,
6 recorder for QDR application (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)

ibaQDR-1024-32

35.710240
Quality Data Recording with 1024 signals,
32 recorder for QDR application (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)

ibaQDR-2048-48

35.720480
Quality Data Recording with 2048 signals,
48 recorder for QDR application (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)

ibaQDR-unlimited-64

35.799990
Quality Data Recording with unlimited signals, 64 recorder for QDR application (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)

ibaQDR-unlimited-96

35.799992
Quality Data Recording with unlimited signals, 96 recorder for QDR application (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)

ibaQDR-Measuring-Location

35.700001
Quality Data Recording:
Measuring Points/Machines; Extension licence (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)
